Grundfos SQ Submersible Pump 3" / 76mm Well Borehole SQ 1-35 MS3 0,58kW 1x230V 50/60Hz

Grundfos SQ Submersible Pump 3" / 76mm Well Borehole SQ 1-35 MS3 0,58kW 1x230V 50/60Hz
Price:

559,00 VAT included (22%)

Freight costs:
MPN: 96510178
EAN: 5700396503776
Availability: Available Handling Time: Immediate delivery
Quantity:

Users feedback

Description

Technical details

Pump Type: SQ 1-35 MS 3
Voltage: 1x230V 50/60Hz
Input Power, Motor P1 [kW]: 0,58
Output Power, Motor P2 [kW]: 0,7
Required Input Power, Pump [kW]: 0,37
Flow Rate Q [l/min]: 8,4÷25,2
Head H [m]: 43÷20
Thread Connections: 1"1/4
Power Cable [m]: 1,5
Pump Body: Stainless Steel AISI304
Impeller Material: Polyamide

GRUNDFOS SQ RANGE - SUBMERSIBLE PUMPS

The SQ pump is Grundfos’ most compact submersible solution for ground water extraction.
A mere 3" in diameter, the long, lean pump fits nicely into small boreholes of the same size – or in 4" boreholes that over time have become smaller due to ochre deposits.
The compact design along with key features like dryrunning protection and soft start to reduce wear on motor makes the SQ pump one of the most reliable choices for submersible operation.

BENEFITS

Unique 3" design
Wide voltage window
Soft start – reduces wear on motor and minimises stress of the entire installation
Dry-running protection
Overload protection
Automatic restart
All stainless steel exterior design – reduces risk of corrosion to a minimum
Built-in electronics – facilitate installation and operation

APPLICATIONS

Domestic water supply
Small water works
Irrigation systems
Groundwater lowering

KEY FEATURES

Soft start and low amp draw
High starting torque & deep setting handling
2 wire & no extra box needed
Handle voltage fluctuation, protection and automatic restart
Dry-running protection
Soft start
Built-in electronics
Permanent magnet motors

TECHNICAL DATA

Nominal voltage range: 1x200-240V
Frequency: 50/60Hz
Max. acceptable media temp: 30 °C (40 °C)
Pump diameter: Ø74 mm
Weight (min./max.): 4.7-6.4 kg
Thread connections: RP 1¼ / RP 1½
Minimum well diameter: Ø76 mm
Materials (Stainless steel): SQ - DIN W.-Nr. 1.4301, AISI 304
The SQ pump can be installed vertically or horizontally

Data sheet GRUNDFOS SQ1-35
