PEDROLLO PQ60 water Pump industrial with peripheral impeller for Irrigation 400V

Price:	€149,57 VAT included (22%)
Freight costs:	FreeDetails
MPN:	41PNQ60A
EAN:	8052230000925
Availability:	Available Handling Time: Immediate delivery
Quantity:	PEDROLLO PQ60 water Pump industrial with peripheral impeller for Irrigation 400V How many PZ do you want to add?

Services

Print Ask for information

Users feedback

Description

Technical details

Model	PQ60
Power	Three-phase
kW	0,37
HP	0,5
Flow Rate Q [l/min]	5 ÷ 40
Head H [m]	38 ÷ 5
Outlet	1"
Pump body	Cast Iron
Impeller	Brass

PQ Pumps with peripheral impeller

INSTALLATION AND USE

The hydraulic characteristics of these pumps, coupled with their compactness, makes them suitable for use in both domestic and industrial applications.
Suitable for use with clean water that does not contain abrasive particles and liquids that are not chemically aggressive towards the materials from which the pump is made.
The pump should be installed in an enclosed environment, or at least sheltered from inclement weather.

Features

Liquid type: Clean Water
Uses: domestic
Applications: irrigation pumps, cooling systems, air conditioning systems, ironing system, washing systems, water supply systems, pressure systems
typology: surface
Family: peripheral

Application Limit:

Temperature of the liquid from -10 °C to +90 °C
Ambient temperature between -10 °C and +40 °C (+50 °C for PQ 60)
Manometric suction lift up to 8 m
Max. working pressure:
– 6 bar for PQ 60, PQ 65
– 7 bar for PQ 70, PQ 80
– 10 bar for PQ 90, PQ 100, PQ 200, PQ 300
Continuous service S1
