Pedrollo 4BLOCK 4” Monoblock Submersible Borehole Pump 4BLOCKm 4/9 0,75 kW 1Hp Monophase Cable 20 Mt Body STAINLESS STEEL AISI 304 Impeller LEXAN
€392,50 VAT included (22%)
|Availability:||Available Handling time: 10 business days|
|Diameter Pump||4 inches - 100 mm|
|Power Supply||Single Phase 230V 50Hz|
|Liquid Type||Clean Water - Maximum sand content 150 g/mc|
|Flow Rate Q L/min||20 ÷ 100|
|Head H Metres||56 ÷ 23|
|Power Cable||20 meter|
|Pump Body||Stainless Steel AISI 304|
INSTALLATION AND USE
Ready to install, stainless steel monoblock submersible pump. Complete with: motor with built-in capacitor and thermal overload protector 20 m long power cable. Suitable for pumping clean water from boreholes that contain sand (up to 150 g/m³). As a result of their high efficiency and reliability they are suitable for use in domestic applications such as domestic water supply as part of a pressure supply and for irrigation, etc.
Liquid type: clean water
Uses: domestic, civil, agriculture
water supply systems, pressure systems, irrigation pumps.
Family: submersible monoblock pumps 4"
Temperature of the liquid to +35 °C
Maximum sand content 150 g/m³
Maximum immersion depth of 60 m with a sufficiently long power cable
Vertical and horizontal installation
Starts/hour: 20 at regular intervals
Continuous service S1
